Clear Scan Radiolucent A10032RT-5NB

+ View Larger

6502952V - Clear Scan Radiolucent Electrodes - 1 per Ea

Product Line
ClearScan™

Quantity Per
1 Per Pouch

Application
Monitoring in CathLab, X-Ray, and thallium testing procedures

Size
1.875 in / 47.625 mm

Shape
Teardrop

Substrate Material
Polyolefin Tape

Gel Type
Conductive Solid Hydrogel

Reference Number
A10032RT-5NB

Duration Of Use
72 Hours

Adhesive Strength
Regular

MRI Conditional
Yes

Cross Reference:

A10032RT-5NB

Load More +

| Hide All

Price:

In Stock

- Ships 3/13/2026
Qty On Hand: 1,797

Min Qty
600 Ea

Pkg. Multiple
600 Ea

UOM
Ea

# Per UOM
1

More Information

Graphic Controls Part Number:	6502952V
Product Type:	Medical
OEM Equipment:	Clear Scan Radiolucent
Adaptor	Carbon Filled ABS
Xray Translucent	Yes
Shelf Life Months	24
Repositionability	No
Sensor Diameter (in)	0.417
Sensor Diameter (mm)	10.592
Substrate Thickness (in)	0.005
Substrate Thickness (mm)	0.127
Total Surface Area (in²)	2.7973
Total Surface Area (mm²)	71.0516
Gel Area (in²)	0.3068
Gel Area (mm²)	7.7927
Adhesive Area (in²)	2.4905
Adhesive Area (mm²)	63.2588
Resealable Pouch	Yes
Lead Wire Length (in)	N/A
Lead Wire Color
Adhesive	Acrylic, Medical Grade
Release Liner	PS
Sensor Polymer	Ag/AgCl plated ABS
Lead Wire Jacketing	N/A
Lead Wire Cord	N/A
Packaging Material	Paper/PE/Foil/PE
Packaging Size LxW (in)	14.5 x 10.875 x 6.75
Packaging Size LxW (cm)	36.83 x 27.623 x 17.145
Carton Size / Qty (in)	n/a
Carton Size / Qty (cm)	n/a
Passed ISO 10993	Passed
Latex Free	Yes
Sensitive Skin Compatible
Any Halogenated Hydrocarbon Content	None
Any Pthalate Derivative Content	None
RoHS Compliance	Yes
REACH	Yes
Regulatory Status	CE Mark according to MDD 93/42/EEC CE marked
ACZ Impedance (Ohm)	57
DC Voltage Offset (mV)	0.22
SDR Slope (mV/s)	0.07
ACZ Impedance Repeat (Ohm)	47
COIIN (uV)	7
Bias Current Tolerance (mV)	4
Pediatric	No
Foam Sponge Material	N/A
Size Length Width (cm)	22.86 x 33.02
Size Length Width (in)	9 x 13
Integrated Abrader	No
Quantity Per	1
